BAR18-OV8N
Linear Analog Output Sensor
- Good linear output for machine stability control
- Application : RPM and displacement control
- Two outputs models : 0~10V / 4~20mA
- Excellent repeatability
Technical Data
| Parameters | Details |
|---|---|
| Output | 0-10V |
| Sensing Distance | 8 mm |
| Standard Sensing Object | Iron 18 x 18 x 1 mm |
| Ripple | ≤20% |
| Operating Voltage | DC 15 ~ 24V |
| Current Consumption | 35 mA Max. |
| Load Resistance | >10KΩ 0~10V |
| Output Protection | Input power polarity reversal protection / Output power short-circuit protection |
| No-load Supply Current | ≤10mA |
| Temperature Drift | ≤15% Sr |
| Insulation Resistance | 20M Ω min. (DC 500V) |
| Voltage with Standability | AC1000V 60Hz for 60 Sec. |
| Voltage with Standability | - 20ºC ~ + 60ºC |
| Operating Temperature | 35% ~ 85% RH |
| Material | IP67 |
| Wiring Method | Pre-wired Ø5.2 x 2 M / 3wires |
| Weight | Approx.93g |
Dimension Drawing
Connection Diagram
