- 2-Wire type
- SPST, Normally Open
- IP 67
| Parameters | Details |
| Wiring Method | 2-Wire type |
| Switching Logic | SPST, Normally Open |
| Sensor Type | Reed Switch |
| Operating Voltage | 5 ~ 240 V DC / AC |
| Switching Current | 100 mA max. |
| Contact Rating | 10 W max. |
| Current Consumption | - |
| Voltage Drop | 3.5 V max. |
| Leakage Current | - |
| Indicator | Green LED |
| Cable | ø4, 2C, PVC |
| Operating Frequency | 200 Hz |
| Magnet Requirement | 80 Gauss |
| Temperature Range | -10 ~ 70 ˚C |
| Shock | 30 G |
| VIbration | 9 G |
| Enclosure Classification | IEC 60529 IP67 |
| Protection Circuit | 1 |
