| Sensing Type | Diffuse Reflection |
| Sensing Distance | 300mm (white paper 300X300mm) |
| Emitting light | Infrared LED 850nm |
| Operating Voltage | 12~ 24VDC |
| Current Consumption | 25 mA Max. |
| Load current | 100mA Max. at DC24V |
| Output type | NPN(NO) Dark on / NPN(NC) Light on |
| Response time | 1.5 ms Max. |
| Insulation resistance | 20MΩ min. (DC500V) |
| Voltage with standabiligy | AC1000V 60Hz for 60 Sec. |
| Operating temperature | -20°C ~ + 60°C |
| Ambient humidity | 35% ~ 85% RH |
| Protection degree | IP64 |
| Material | ABS |
| Wiring method | Pre-wired Ø4.2 x 2 M / 4-wires |
| Weight | Approx. 60g |
