| Sensing Distance | 18 mm |
| Detection Object | Opaque |
| Emitting Light | Infrared LED 940nm |
| Operating Voltage | 12~24 VDC |
| Current Consumption | 35 mA Max. |
| Load Current | 100mA Max. at 24VDC |
| Output Type | PNP(NO) Dark on / PNP(NC) Light on / NPN(NO) Dark on / NPN(NC) Light on |
| Response Time | 1 ms Max. |
| Ambient Illumination | Incandescent light 5,000 lux max. |
| Insulation Resistance | 20MΩ min. (DC500V) |
| Voltage with Standabiligy | AC1000V 60Hz for 60 Sec. |
| Operating Temperature | -10°C ~ + 55°C (No freezing allowed) |
| Ambient Humidity | 45% ~ 85% RH |
| Protection Degree | IP65 |
| Vibration Resistance | 1.5-mm peak-to-peak amplitude, 10 to 55 Hz, 2 hours each in X, Y, and Z directions |
| Shock Resistance | 50G, repeated 10 times each in X, Y, and Z directions |
| Material | ZINC / Nickel-plated zinc alloy |
| Wiring Method | Pre-wired Ø4.2 x 2 M / 4-wires |
| Weight | Approx.70g |
