| Channel 1 | Channel 2 |
| DC output Voltage, Current | 5V 0~4A | 12V 0~1A |
| Wave and Noise | 50mVp-p | 100mVp-p |
| Inlet Wire Stability | ± 0.5% | ± 1% |
| Load Stability | ± 0.5% | ± 4% |
| Efficiency | 72% | 72% |
| Adjustable Range for DC Voltage | ± 10% | ± 5% |
| Input Voltage Range | 90~132VAC / 180~264VAC by switch 254~370VDC 47~63Hz | - |
| Impact Current | 18A/115VAC 36A/230VAC Cold start current | - |
| Overload Protection | 105%~150% cut off the output, automatic recovery | - |
| Setup, Rise, Hold up time | 200ms, 50ms, 30ms/230VAC at full load | - |
| Withstand Voltage | I/P–O/P: 1.5kV I/P–FG: 1.5kV O/P–FG 0.5kV 1minute | - |
| Isolation Resistance | I/P–O/P I/P–FG O/P–FG: 500VDC/100MΩ | - |
| Working Temperature | – 10°C ~ +50°C | - |
| Dimension and Weight | 0.4kg 129 x 98 x 38mm | - |
