| DC output Volt, Current, Power | 24V, 6.5Amp., 150W |
| Efficiency | 89% |
| Dimension | 164*97*30mm |
| Input Voltage | 110/220VAC ±20% |
| Input Current | 3A/115VAC / 1.7A/230VAC |
| Voltage Adj. Range | 21.6 ~ 28.8V |
| Cooling | By free air convection cooling |
| Ripple and Noise 1 | 200mVp-p |
| Inrush Current (typ.) | 60A/230VAC |
| Over Load protection 2 | 110%~140% rated output power |
| Setup, Rise, Time at full load | 500ms, 30ms/230VAC / 500ms, 30ms/115VAC |
| Load Regulation 3 | ± 0.5% |
| Withstand Voltage | I/P–O/P: 1.5kV I/P–FG: 1.5kV O/P–FG: 0.5kV |
| Isolation Resistance | I/P–O/P I/P–FG O/P–FG: 500VDC/100MΩ |
| Working Temp., Humidity | – 30°C ~ +50°C / 20~90% RH non-condensing |
