| DC output Volt, Current, Power | 24V, 14.6Amp., 350W |
| Efficiency | 88% |
| Dimension | 215*115*30mm |
| Input Voltage | 110/220VAC ±20% |
| Input Current | 6.8A/115VAC / 3.4A/230VAC |
| Voltage Adj. Range | 21.6 ~ 28.8V |
| Cooling | Fan |
| Ripple and Noise 1 | 150mVp-p |
| Inrush Current (typ.) | 60A/115/230VAC |
| Over Load protection 2 | 110%~140% rated output power |
| Setup, Rise, Time at full load | 1300ms, 50ms/230VAC / 1300ms, 50ms/115VAC |
| Load Regulation 3 | ± 1% |
| Withstand Voltage | I/P–O/P: 1.5kV I/P–FG: 1.5kV O/P–FG: 0.5kV |
| Isolation Resistance | I/P–O/P I/P–FG O/P–FG: 500VDC/100MΩ |
| Working Temp., Humidity | – 30°C ~ +50°C / 20~90% RH non-condensing |
